Emas MN2MIM1Y Basic Switch
Product Code: EMS-MN2MIM1Y
Made to order — we confirm the delivery date with your order
Product Description
Metal Short Lever Roller 1CO MN2 Series Plastic Mini Switch
Emas MN2MIM1Y Basic Switch
- Maximum product reliability with V0 material
- Different actuator options
- Standard mounting holes
Emas MN2MIM1Y Basic Mini Switch - Metal Short Lever Roller
The Emas MN2MIM1Y is a high-performance basic mini switch from the enhanced MN2 series, specifically engineered for industrial applications requiring precise mechanical sensing in compact spaces. This model is equipped with a durable metal short lever roller actuator, providing a sensitive interface for smooth mechanical triggering with significantly reduced friction. Built with premium V0 flame-retardant material, the MN2MIM1Y ensures maximum product reliability and high-level operational safety. Featuring a 1CO (Changeover) contact configuration and standardized mounting holes, it offers seamless integration into control systems, appliances, and automated machinery where accuracy, durability, and a small footprint are essential.
Technical Excellence
- V0 Rated Housing: Manufactured with top-tier flame-retardant material for peak safety
- Metal Short Lever Roller: Durable actuator designed for smooth mechanical triggering
- 1CO Contact Configuration: Versatile Changeover contact for flexible electrical wiring
- High Electrical Capacity: Rated for 6A at 250V AC (AC15) for reliable switching
- Extended Service Life: Designed for up to 500,000 mechanical operations
- Standardized Mounting: Features industry-standard holes for easy replacement
Operational Advantages
- Friction Reduction: Roller tip minimizes mechanical wear on target components
- Maximum Reliability: Robust internal mechanism ensures long-term performance
- Superior Insulation: High insulation voltage (Ui) of 660V for industrial safety
- AgNi Contacts: Features silver-nickel alloy for superior electrical conductivity
- Environmental Resilience: Operates efficiently between -25°C and +80°C
- Certified Quality: Fully compliant with TS EN 60947-5-1 standards
Technical Specifications
| Model / Code | Emas MN2MIM1Y |
|---|---|
| Series | MN2 Plastic Mini Switch |
| Actuator Type | Metal Short Lever Roller |
| Thermal Current (Ith) | 10 A |
| Rated Current (Ie) | 6 A (250V AC, AC15) |
| Contact Configuration | 1CO (Changeover / Enversör) |
| Insulation Voltage (Ui) | 660 V |
| Impulse Voltage (Uimp) | 2.5 kV |
| Mechanical Life | 500,000 operations |
| Body Material | V0 Flame-Retardant Plastic |
| Standard Compliance | IEC/EN 60947-5-1 |
Technical Datasheet
For detailed wiring diagrams, dimensions, and electrical trip curves, view the official EMAS datasheet.
