Emas MN4PUP1 Basic Switch
Product Code: EMS-MN4PUP1
Made to order — we confirm the delivery date with your order
Product Description
Emas MN4PUP1 Basic Switch
Plastic Thin Plunger 1NO+1NC MN4 Series Plastic Mini Switch
Emas MN4PUP1 Basic Switch
- Maximum product reliability with V0 material
- Different actuator options
- Standard mounting holes
Emas MN4PUP1 Basic Mini Switch - Plastic Thin Plunger (1NO+1NC)
The Emas MN4PUP1 is a high-precision basic mini switch from the specialized MN4 series, engineered for industrial automation applications requiring a dual-contact (1NO+1NC) configuration in a compact footprint. This model features a durable plastic thin plunger actuator, providing a concentrated point of contact for precise vertical mechanical triggering. Built with premium V0 flame-retardant material, the MN4PUP1 ensures maximum product reliability and high-level operational safety. With its standardized mounting holes and robust internal mechanism, it offers seamless integration into control systems, appliances, and automated machinery where precision, dual-circuit control, and compact design are essential.
Technical Excellence
- V0 Rated Housing: Manufactured with top-tier flame-retardant material for peak industrial safety
- Plastic Thin Plunger: Precise actuator designed for vertical mechanical triggering in restricted spaces
- 1NO+1NC Contacts: Dual-circuit configuration for simultaneous normally open and normally closed operations
- Specialized MN4 Series: Optimized internal construction for reliable multi-contact switching
- Standardized Mounting: Features industry-standard holes for easy installation and maintenance
- High Sensitivity: Engineered for rapid switching response with minimal actuation force
Operational Advantages
- Space-Saving Design: Miniature form factor ideal for high-density control panels
- Circuit Versatility: Suitable for applications requiring both signal feedback and safety interlocks
- Maximum Reliability: Robust internal mechanism ensures a long service life in repetitive cycles
- Superior Insulation: High dielectric strength body provides reliable electrical separation
- Precision Vertical Sensing: Thin plunger allows for accurate detection of small target components
- Global Standards: Engineered to meet international IEC/EN 60947-5-1 safety requirements
Technical Specifications
| Model / Code | Emas MN4PUP1 |
|---|---|
| Series | MN4 Plastic Mini Switch Series |
| Actuator Type | Plastic Thin Plunger (Plastik İnce Pim) |
| Contact Configuration | 1NO + 1NC (Normally Open + Normally Closed) |
| Rated Current (Ie) | 6 A (250V AC, AC15) |
| Thermal Current (Ith) | 10 A |
| Body Material | V0 Flame-Retardant Plastic |
| Insulation Voltage (Ui) | 660 V |
| Impulse Voltage (Uimp) | 2.5 kV |
| Contact Material | AgNi (Silver-Nickel Alloy) |
| Standard Compliance | IEC/EN 60947-5-1 |
Technical Datasheet
For detailed wiring diagrams, contact ratings, and dimensions, view the official EMAS datasheet.
