Finder 41.81.7.012.9024 Solid State Relay
Product Code: FINDER-41.81.7.012.9024
Made to order — we confirm the delivery date with your order
Product Description
Finder 41.81.7.012.9024 Solid State Relay
Solid State Relay: 5A-24VDC,12DC
Finder 41.81.7.012.9024 Solid State Relay
Finder 41.81.7.012.9024 Solid State Relay - 5A 24VDC / 12VDC
The Finder 41.81.7.012.9024 is a high-performance, ultra-slim DC-DC Solid State Relay (SSR) designed for precision switching of DC loads in industrial automation and electronic control systems. This model is capable of handling up to 5A at 24VDC, making it ideal for controlling solenoid valves, DC motors, and high-power LED systems with a standard 12VDC control signal. Engineered for PCB mounting or socket integration, the 41.81 series provides silent, wear-free operation with high-speed switching capabilities. Its solid-state architecture ensures immunity to mechanical vibrations and offers an exceptionally long electrical life, providing a reliable solution for applications where traditional electromechanical relays may reach their operational limits.
Technical Excellence
- High DC Capacity: Capable of switching 5A DC loads at 24V DC with high efficiency
- Slim Profile: Low-profile 15.7 mm height designed for high-density PCB boards
- DC Control / DC Load: 12V DC input sensitivity optimized for modern control circuits
- Silent Operation: Fully electronic switching eliminates mechanical noise and contact arcing
- Fast Response: High-speed turn-on and turn-off times for precision timing applications
- Socket Compatibility: Seamlessly integrates with Finder 93 Series sockets for easy maintenance
Operational Advantages
- Maintenance-Free: No moving parts means no contact wear, leading to unlimited electrical cycles
- Shock & Vibration Resistant: Solid-state build ensures reliability in mobile or vibrating machinery
- Low Driving Power: Requires very low input power, ideal for direct PLC and microcontroller driving
- Compact Integration: Occupies minimal space while providing significant current switching power
- Enhanced Safety: High input-to-output dielectric strength ensures protection of sensitive control electronics
- Industrial Quality: Compliant with international standards for safety and operational reliability
Technical Specifications
| Model / Code | Finder 41.81.7.012.9024 |
|---|---|
| Relay Type | Solid State Relay (SSR) - DC Switching |
| Mounting Type | PCB or Socket (93 Series) |
| Control Voltage (Input) | 12 V DC |
| Rated Load (Output) | 5 A / 24 V DC |
| Contact Configuration | 1 NO (Normally Open) |
| Output Circuit | DC Switching (Transistor) |
| Dielectric Strength | 2500 V AC (Input to Output) |
| Ambient Temperature | -20°C to +60°C |
| Dimensions | 32.7 x 15.7 x 12.7 mm |
| Standard Compliance | CE, EAC, cULus Approved |
Technical Datasheet
For detailed electrical derating curves, response times, and wiring diagrams, view the official Finder datasheet.
