GIGAVAC G23WF DPDT High Voltage Relay
Product Code: G23WF
In stock — 3 available
Product Description
GIGAVAC G23WF DPDT High Voltage Relay
The GIGAVAC G23WF DPDT Relay features two normally open and two normally closed contacts within a single unit. Its tungsten/moly contacts ensure excellent load switching performance. Designed with a compact footprint, it optimizes space efficiency in various applications. The relay can be mounted in any orientation for flexible installation.
| Specifications | |
| Voltage Rating | 20kV |
| Rated Voltage (KV Peak) DC or 60Hz | 20kV Peak |
| Max. Carry (Amps) DC or 60Hz | 75 |
| Contact Arrangement | Double Pole Double Throw |
| Max. Contact Res. (Ohms) | 0.010 |
| Max. Operate Time (ms) | 30 |
| Max. Release Time (ms) | 10 |
| Mech. Life (cycles) | 1 million |
| Downloads | |
| Datasheet | [reblex id='10889'] Download |
GIGAVAC G23WF High Voltage Relay - DPDT 20kV 75A
The GIGAVAC G23WF is a high-performance Double Pole Double Throw (DPDT) high voltage relay, engineered for demanding power switching applications requiring extreme reliability. Featuring a specialized tungsten/molybdenum contact structure, it delivers excellent load switching performance and a high current carry capacity of up to 75A. Its unique design incorporates two normally open and two normally closed contacts within a single, compact unit, optimizing space efficiency without compromising on insulation. With a 20kV voltage rating and the flexibility to be mounted in any orientation, the G23WF is an ideal solution for advanced industrial control systems and high-voltage power distribution.
Technical Excellence
- 20kV Voltage Rating: Engineered for high-voltage DC and 60Hz peak switching safety
- High Current Carry: Capable of managing continuous loads up to 75 Amps
- DPDT Configuration: Features 2NO and 2NC contacts in a single integrated unit
- Tungsten/Moly Contacts: Optimized material for superior load switching durability
- Low Resistance: Maximum contact resistance maintained at a precise 0.010 Ohms
- Long Mechanical Life: Built to withstand up to 1 million operational cycles
Operational Advantages
- Space Optimization: Compact footprint designed for high-density power panels
- Flexible Installation: Can be mounted in any orientation to suit complex layouts
- Rapid Response: Features a maximum operate time of 30ms and release time of 10ms
- Industrial Grade Build: Highly resistant to environmental stress in critical applications
- Switching Versatility: Ideal for power polarity reversal and dual-circuit control
- GIGAVAC Reliability: Manufactured to meet the highest international safety standards
Technical Specifications
| Model / Code | GIGAVAC G23WF |
|---|---|
| Contact Arrangement | DPDT (Double Pole Double Throw) |
| Voltage Rating | 20 kV |
| Rated Voltage (Peak) | 20 kV Peak (DC or 60Hz) |
| Max. Carry Current | 75 A (DC or 60Hz) |
| Max. Contact Resistance | 0.010 Ω |
| Max. Operate Time | 30 ms |
| Max. Release Time | 10 ms |
| Mechanical Life | 1,000,000 cycles |
| Contact Material | Tungsten / Moly |
Technical Datasheet
For detailed mechanical drawings, mounting patterns, and high-voltage safety guidelines, view the official GIGAVAC datasheet.
