RODA JEN–S1-O Finger Type Joystick
RODA JEN–S1-O Finger Type Joystick
The **RODA JEN–S1 Series** is a newly constructed finger-operated joystick featuring a space-saving design optimized for medium-duty industrial applications. Engineered for precision and economy, it offers reliable two-axis control (X and Y directions) with a high-integrity spring return mechanism. Each direction is equipped with 1NO+1NC micro-switches, ensuring versatile electrical interfacing. With an **IP65 protection class** for the above-panel components, it is an ideal solution for compact control consoles requiring long mechanical life and robust performance.
Product Highlights
- Space-Saving Design: Compact footprint ideal for small to medium consoles
- Switch Configuration: Independent 1NO+1NC micro-switches for every direction
- High Protection: IP65 rated above the panel for dust and water resistance
- Long Service Life: Mechanical endurance rated at 0.2 million cycles
- Micro-switches Rating: High capacity 250Vac / 5A for direct control
- Operation Force: Calibrated between 2.2N and 2.8N for ergonomic feedback
Options & Customization
- Uniaxial Control: Available as a single-axis model
- Push-Button Integration: Optional top-mounted button for auxiliary functions
- Moving Mechanism: 6 distinct patterns (X, Y, L, N, T, O)
- Configuration: Suffix addition for pattern selection (e.g., JEN-S1-O)
Electrical & Mechanical Specifications
| Operation Angle | ±12° from center position |
|---|---|
| Movement Range | 360° Circular |
| Contact Configuration | 1NO + 1NC (for each direction) |
| Insulation Resistance | > 1000 MΩ (500 Vdc) |
| Dielectric Strength | 500 Vac (for 1 minute) |
| Mechanical Life | 0.2 x 10⁶ cycles |
| Operating Temperature | -20°C to +65°C |
| Weight | Approx. 40 g |
