ASM PRAS1-360-U2-CW-M12A5 Sensor
Product Code: PRAS1-360-U2-CW-M12A5
Made to order — we confirm the delivery date with your order
1
Free shipping over $500 to most countries Fast & reliable service
Product Description
ASM PRAS1-360-U2-CW-M12A5 Sensor
The ASM PRAS1 is a high-performance magnetic rotary sensor designed for precision angle measurement from 0 to 360°. Featuring a robust stainless steel housing and non-contact magnetic sensing technology, it offers a completely wear-free solution for demanding industrial environments. With its exceptional IP67/IP69K protection, it is ideal for applications requiring high hygiene standards or resistance to extreme conditions.
Key Features
- Measurement range: 0 to 360°
- Protection class: IP67 / IP69K
- Analog output for precise control
- Durable stainless steel housing
- Non-contact sensing with external magnet
- Wear-free operation for long service life
- SIL (Safety Integrity Level) in preparation
Application Areas
- Food and beverage processing (IP69K)
- Mobile machinery and heavy equipment
- Industrial automation and robotics
- Renewable energy (wind/solar tracking)
- Wash-down industrial environments
| Measurement Range | 0 to 360° |
|---|---|
| Output Type | Analog |
| Protection Class | IP67 / IP69K |
| Housing Material | Stainless Steel |
| Sensing Method | Non-contact (External Position Magnet) |
| Mechanical Life | Wear-free |
| Connection | M12 Connector (A-coded, 5-pin) |
Technical Datasheet
Access detailed electrical diagrams and mounting instructions for the PRAS1 series.
