Omal Srl RV2I Magnetic Reed Sensors
Product Code: Omal-RV2I
In stock — 102 available
1
Free shipping over $500 to most countries Fast & reliable service
Product Description
Omal Srl RV2I, 10 to 240 V AC/DC, PNP, 3mt
Omal Srl RV2I Magnetic Proximity Sensor
The Omal Srl RV2I is a versatile magnetic proximity sensor designed for reliable position detection in industrial automation. Engineered with a wide operating voltage range of 10 to 240 V AC/DC, it is compatible with a vast array of control systems. Featuring a durable PA housing, an IP67 protection rating, and a secure Snap clamping system, this sensor ensures precise switching and high resistance to environmental factors, making it ideal for pneumatic cylinder applications.
Product Highlights
- Universal Voltage: Wide 10-240V AC/DC range for global compatibility
- Rugged Sealing: IP67 rated for protection against dust and water immersion
- Visual Feedback: Integrated Yellow LED for instant operation status
- Easy Installation: Snap-on clamping system for rapid and secure mounting
- Pre-Wired Convenience: Includes a high-quality 3-meter PVC cable
- Wide Thermal Range: Reliable operation from -20°C to +85°C
Primary Applications
- Pneumatic Cylinders: End-stroke and position sensing for actuators
- Automated Valves: Open/Close feedback for rotary and linear process valves
- Industrial Robotics: Position monitoring for robotic grippers and joints
- Packaging Machinery: High-speed limit sensing in conveyor lines
- Machine Tools: Safe interlocking and component presence detection
- Material Handling: General proximity sensing in adverse environments
Technical Specifications
| Operating Voltage | 10 to 240 V AC/DC |
|---|---|
| Switching Current (max.) | 400mA @ 25°C |
| Operation Indicator | Yellow LED |
| Working Temperature Range | -20°C to +85°C |
| Maximum Load | 10W DC / 8VA AC |
| Protection Class | IP67 (Dust/Waterproof) |
| Housing Material | Polyamide (PA) |
| Cable Specification | 3m PVC Cable (3×0.14 mm²) |
| Clamping System | Snap-on Mounting |
Technical Documentation
Access the official technical documentation for detailed wiring diagrams, mounting instructions, and dimensional data.
