GIGAVAC P195FDA MiniTACTOR
Product Code: P195FDA
Made to order — we confirm the delivery date with your order
Product Description
GIGAVAC P195FDA MiniTACTOR
The GIGAVAC P195FDA, part of the MiniTACTOR™ series, is a compact, lightweight, and budget-friendly power contactor. It is designed and manufactured in the USA.
The P-Series contactor can be quickly installed in any position on a panel or PCB. Both the coil and contacts are enclosed in a hermetically sealed chamber, ensuring reliable switching in various environmental conditions. Additionally, P-Series contactors are significantly lighter than other models, weighing less than 140 grams.
GIGAVAC P195FDA MiniTACTOR™ - 80A 48V-1500VDC
The GIGAVAC P195FDA, a high-performance member of the specialized MiniTACTOR™ series, is an ultra-compact power contactor engineered for high-voltage DC applications where space, weight, and reliability are critical constraints. Designed and manufactured in the USA, this lightweight unit (only 135g) is capable of switching loads up to an impressive 1500VDC with a continuous current rating of 80A. Its hermetically sealed chamber protects both the 48Vdc coil and the contacts, ensuring consistent load-break performance and safety in hazardous or harsh environmental conditions. With an exceptional mechanical life of one million cycles and flexible mounting options, the P195FDA is a premier solution for advanced high-voltage power management infrastructure.
Product Highlights
- Extreme Voltage Capacity: Reliable switching for DC loads up to 1500VDC
- 80A Rated Current: Robust power handling in a compact MiniTACTOR™ frame
- 48Vdc Nominal Coil: Optimized for high-voltage control architectures
- Hermetically Sealed: Safe operation in hazardous, wet, or dusty environments
- Superior Longevity: Rated for a mechanical life of 1,000,000 cycles
- Total Protection: Fully rated for IP67 and IP69K environmental standards
Fields of Use
- Electric Vehicles (EV) and High-Voltage Charging Infrastructure
- Solar Power Systems and Photovoltaic Inverters
- Advanced Battery Management Systems (BMS)
- High-Voltage DC Energy Storage Systems (ESS)
- Industrial Automation and Heavy-Duty DC Controls
- Defense and Aerospace Power Distribution Units
Technical Specifications
| Contact Arrangement | SPST-NO (Normally Open) |
|---|---|
| Contact Voltage, Operating Max. | 1500Vdc |
| Coil Voltage, Nominal | 48Vdc |
| Rated Current | 80A |
| Mechanical Life | 1,000,000 Cycles |
| Operating Temperature | -40 to +85 °C |
| Auxiliary Contact | None |
| IP Rating | IP67 and IP69K |
| Weight | 135 Grams |
Technical Datasheet
Download the official GIGAVAC P195FDA MiniTACTOR™ datasheet for comprehensive technical documentation, including mounting footprints, terminal configurations, and performance curves.
